NXT系列：NXT FUJI NXT H01、NXT FUJI NXT H04、NXT FUJI NXT H08、NXT FUJI NXT H12
1 FUJI NXT H08/FUJI NXT H12 AA1AT04 Nozzle R07-003-070
2 FUJI NXT H08/FUJI NXT H12 AA05603 Nozzle R07-004-070
3 FUJI NXT H08/FUJI NXT H12 AA05703 Nozzle R07-007-070
4 FUJI NXT H08/FUJI NXT H12 AA05803 Nozzle R07-010-070
5 FUJI NXT H08/FUJI NXT H12 AA20A03 Nozzle R07-013-070
6 FUJI NXT H08/FUJI NXT H12 AA20B03 Nozzle R07-018-070
7 FUJI NXT H08/FUJI NXT H12 AA20C03 Nozzle R07-025-070
8 FUJI NXT H08/FUJI NXT H12 AA20D03 Nozzle R07-037-070
9 FUJI NXT H08/FUJI NXT H12 AA20E03 Nozzle R07-050-070
10 FUJI NXT H08/FUJI NXT H12 AA06404 Nozzle R07-013M-070
11 FUJI NXT H08/FUJI NXT H12 AA19G04 Nozzle R07-018M-070
12 FUJI NXT H08/FUJI NXT H12 AA06504 Nozzle R07-025M-070
13 FUJI NXT H08/FUJI NXT H12 AA0WT05 Nozzle R07-025G-070
14 FUJI NXT H08/FUJI NXT H12 AA18C02 Nozzle R07-037G-070
15 FUJI NXT H08/FUJI NXT H12 AA06302 Nozzle R07-050G-070
16 FUJI NXT H04 AA06W07 Nozzle R19-010-155
17 FUJI NXT H04 AA06X08 Nozzle R19-013-155
18 FUJI NXT H04 AA06Y08 Nozzle R19-018-155
19 FUJI NXT H04 AA06Z09 Nozzle R19-025-155
20 FUJI NXT H04 AA07A09 Nozzle R19-037-155
21 FUJI NXT H04 AA07B08 Nozzle R19-050-155
22 FUJI NXT H04 AA07C06 Nozzle R19-070-155
23 FUJI NXT H04 AA07D05 Nozzle R19-100-155
24 FUJI NXT H04 AA07E06 Nozzle R19-150-155
25 FUJI NXT H04 AA07F07 Nozzle R19-025G-155
26 FUJI NXT H04 AA07G05 Nozzle R19-037G-155
27 FUJI NXT H04 AA07FUJI NXT H05 Nozzle R19-050G-155
28 FUJI NXT H04 AA07K05 Nozzle R19-070G-155
29 FUJI NXT H04 AA07L05 Nozzle R19-100G-155
30 FUJI NXT H04 AA07M07 Nozzle R19-150G-155
31 FUJI NXT H01 AA0AS12 Nozzle R36-010-260
32 FUJI NXT H01 AA06812 Nozzle R36-013-260
33 FUJI NXT H01 AA0FUJI NXT HL08 Nozzle R36-018-260
34 FUJI NXT H01 AA0FUJI NXT Hm08 Nozzle R36-025-260
35 FUJI NXT H01 AA0FUJI NXT Hn08 Nozzle R36-037-260
36 FUJI NXT H01 AA0FUJI NXT HR08 Nozzle R36-050-260
37 FUJI NXT H01 AA08013 Nozzle R36-070-260
38 FUJI NXT H01 AA08113 Nozzle R36-100-260
39 FUJI NXT H01 AA08209 Nozzle R36-150-260
40 FUJI NXT H01 AA08309 Nozzle R36-200-260
41 FUJI NXT H01 AA0MZ08 Nozzle R36-013M-260
42 FUJI NXT H01 AA11R08 Nozzle R36-018M-260
43 FUJI NXT H01 AA0ML09 Nozzle R36-025M-260
44 FUJI NXT H01 AA08415 Nozzle R36-025G-260
45 FUJI NXT H01 AA08516 Nozzle R36-037G-260
46 FUJI NXT H01 AA07216 Nozzle R36-050G-260
47 FUJI NXT H01 AA07318 Nozzle R36-070G-260
48 FUJI NXT H01 AA07417 Nozzle R36-100G-260
49 FUJI NXT H01 AA07513 Nozzle R36-150G-260
50 FUJI NXT H01 AA07612Nozzle R36-200G-260
FUJI NXTIII H08M NOZZLE 0.45 R19-004-155-M FUJI AA8LS07
FUJI NXTIII H08M NOZZLE 0.7 R19-007-155-M FUJI AA8DX11
FUJI NXTIII H08M NOZZLE 1 .0 R19-010-155-M FUJI AA8LT08
FUJI NXTIII H08M NOZZLE 1.3 R19-013-155-M FUJI AA8DY11
FUJI NXTIII H08M NOZZLE 1.8 R19-018-155-M FUJI AA8LW07
FUJI NXTIII H08M NOZZLE 2.5 R19-025-155-M FUJI AA8LX08
FUJI NXTIII H08M NOZZLE 3.75 R19-037-155-M FUJI AA8LY08
FUJI NXTIII H08M NOZZLE 5.0 R19-050-155-M FUJI AA8LZ12
FUJI NXTIII H08M NOZZLE 7.0 R19-070-155-M FUJI AA8MA08
FUJI NXTIII H08M NOZZLE 10.0 R19-100-155-M FUJI AA8MB06
FUJI NXTIII H08M NOZZLE 15.0 R19-150-155-M FUJI AA8MC06
FUJI NXTIII H08M NOZZLE 1.3M R19-013M-155-M FUJI AA8MN04
FUJI NXTIII H08M NOZZLE 1.8M R19-018M-155-M FUJI AA8MR04
FUJI NXTIII H08M NOZZLE 2.5M R19-025M-155-M FUJI AA8MS04
FUJI NXTIII H08M NOZZLE 2.5G R19-025G-155-M FUJI AA8ME05
FUJI NXTIII H08M NOZZLE 3.75G R19-037G-155-M FUJI AA8MF04
FUJI NXTIII H08M NOZZLE 5.0G R19-050G-155-M FUJI AA8MG05
FUJI NXTIII H08M NOZZLE 7.0G R19-070G-155-M FUJI AA8MH05
FUJI NXTIII H08M NOZZLE 10.0G R19-100G-155-M FUJI AA8MK05
FUJI NXTIII H08M NOZZLE 15.0G R19-150G-155-M FUJI AA8ML04
FUJII NXT NOZZLES AA06W00 H04 Pink ø1.0
FUJII NXT NOZZLES AA06X00 H04 Green ø1.3 H04 Green ø1.3
FUJII NXT NOZZLES AA06Y00 H04 Aqua ø1.8
FUJII NXT NOZZLES AA22Z14 H04 Orange ø1.8 Melf
FUJII NXT NOZZLES AA06Z00 H04 Aqua ø2.5
FUJII NXT NOZZLES AA07F00 H04 Purple ø2.5G
FUJII NXT NOZZLES AA07A00 H04 Yellow-green ø3.7
FUJII NXT NOZZLES AA07G00 H04 Yellow-green ø3.7g
FUJII NXT NOZZLES AA07B00 H04 Medium purple ø5.0
FUJII NXT NOZZLES AA07H00 H04 Red ø5.0G
FUJII NXT NOZZLES AA07C00 H04 Medium purple ø7.0
FUJII NXT NOZZLES AA07K00 H04 Dark red ø7.0G
FUJII NXT NOZZLES AA07D00 H04 Medium purple ø10.0
FUJII NXT NOZZLES AA07L00 H04 Navy ø10.0G
FUJII NXT NOZZLES AA07E00 H04 Medium purple ø15.0
FUJII NXT NOZZLES AA07M00 H04 White ø15.0G
NXT 二代真空泵，料号：XP00530
2）NXT Y轴丝杆，料号：XB00711
3）NXT H24真空切换阀顶帽和螺丝
4）NXT V12真空阀顶帽：PM0BXE2
5）NXT V12真空阀顶帽螺丝：PZ53012
6）NXT H12真空切换阀，料号：XS01803
7）NXT H04/08真空切换阀，料号：SX01186
8）NXT H24真空切换阀，料号：2MGTHA061200
9）NXT V12真空切换阀，料号：XS03764
10）NXT H12\H12S\H08吸嘴杆卡扣，料号：PM5960
11）NXT H12HS\V12吸嘴杆卡扣，料号：PM074Z1
12）NXT H12\H12S\H08\H12HS\V12吸嘴杆卡扣弹簧，料号：PZ13360
13）NXT NXT H24吸嘴杆卡扣弹簧，料号：2MGTHA044100
14）NXT NXT H24吸嘴杆卡扣，料号：2MCKHA92400＝2MGKHA024200
15）NXT H12HS\H08\V12吸嘴座，料号：ND36A
16）NXT H24吸嘴座，料号：2UGTML00100
17）NXT H12HS吸嘴杆，料号：FUJI AA65D08
18）NXT H04吸嘴杆，料号：FUJI AA32X07
19）NXT H24吸嘴杆，料号：2AGTHA004603＝2SGTHA000500＝2MGKHA028900＝2MGKHA006200
20）H12/H12HS/V12/H04真空切换阀O型圈，料号：A5053C＝A5054X
21）H24真空切换阀O型圈，料号：2MGTTHA059600
22）NXT荧光纸有：PS03562、PS02999902、PS00621、PS00552、PS00141
23）H24头座子，料号：2MGTHA054200
24）NXT气缸有：XS02630、XS02640
25）NXT W12飞达原装全新
26）NXT W16飞达原装全新
27）NXT 一代真空保养包 H5448D
28）NXT 二代真空保养包 H5448E
29）NXT飞达配件和NXT各种皮带
30）NXT V12工作头校正治具 GGAJ0401
31）NXT V12头部锁盖 PP03410
40）NXT 轨道控制卡单轨：XK01940双轨：XK04031
41）NXT 二代CPU卡：XK04643
42）NXT 二代灯罩；XK03721灯罩玻璃；XK01930
43）NXT 三代灯罩整套；2AGTGA004103
44）NXT M3马达型号：SGMAS-01A-FJ13料号；XM00212
FUJI NXT NOZZLE H24 PLACING HEAD
Model Size Part number
NXT III H24 0.19 2AGKNX005102
NXT III H24 0.35 2AGKNX005203
NXT III H24 0.4 2AGKNX005303
NXT III H24 0.45 2AGKNX005402
NXT III H24 0.5 2AGKNX005502
NXT III H24 0.7 2AGKNX003106
NXT III H24 0.725 2AGKNX003302
NXT III H24 1 .0 2AGKNX003504
NXT III H24 1.3 2AGKNX001703
NXT III H24 1.8 2AGKNX003703
NXT III H24 2.5 2AGKNX003903
NXT III H24 1.3 strange nozzle 2.0 2AGKNX004901
NXT III H24 1.3M 2AGKNX004002
NXT III H24 1.8M 2AGKNX004102
NXT III H24 2.5M 2AGKNX004202
NXT III H24 2.5G 2AGKNX001402
FUJI XP 241 341 SMT NOZZLE
Part Number Description
ADEPN8510 FUJI XP2 PICK UP NOZZLE 0.7
ADEPN8520 FUJI XP2 PICK UP NOZZLE 1.0
ADEPN8530 FUJI XP2 PICK UP NOZZLE 1.3
ADEPN8540 FUJI XP2 PICK UP NOZZLE 1.8
ADEPN8550 FUJI XP2 PICK UP NOZZLE 2.5
ADEPN8560 FUJI XP2 PICK UP NOZZLE 3.7
ADEPN8530 FUJI XP3 PICK UP NOZZLE 0.7
ADEPN8540 FUJI XP3 PICK UP NOZZLE 1.0
ADEPN8550 FUJI XP3 PICK UP NOZZLE 1.3
ADEPN8560 FUJI XP3 PICK UP NOZZLE 1.8
DEPN3080 FUJI XP3 PICK UP NOZZLE 5.0
DEPN3089 FUJI XP3 PICK UP NOZZLE 7.0
DEPN3100 FUJI XP3 PICK UP NOZZLE 10
DEPN3110 FUJI XP3 PICK UP NOZZLE 15
DEPN3120 FUJI XP3 PICK UP NOZZLE 20
FUJI XP 142 143 141 SMT NOZZLE
Part Number Description
ADNPN8210 XP-142 NOZZLE ASS’Y-0.7
ADNPN8230 XP-142 NOZZLE ASS’Y-1.0
ADNPN8240 XP-142 NOZZLE ASS’Y-1.3
ADNPN8210 XP-142 NOZZLE ASS’Y-0.7
ADNPN8230 XP-142 NOZZLE ASS’Y-1.0
ADNPN8240 XP-142 NOZZLE ASS’Y-1.3
ADNPN8250 XP-142 NOZZLE ASS’Y-1.8
ADNPN8260 XP-142 NOZZLE ASS’Y-2.5
ADNPN8270 XP-142 NOZZLE ASS’Y-3.7
ADNPN8280 XP-142 NOZZLE ASS’Y-5.0
ADEPN-8070 XP-141 NOZZLE ASS’Y-0.7
ADEPN-8080 XP-141 NOZZLE ASS’Y-1.0
ADEPN-8090 XP-141 NOZZLE ASS’Y-1.3
ADEPN-8100 XP-141 NOZZLE ASS’Y-1.8
FUJI QP341 INDEX SMT NOZZLE
Part Number Description
ADBPN-8123 QP-3 NOZZLE 1.8
ADBPN-8133 QP-3 NOZZLE 2.5
ADBPN-8193 QP-3 NOZZLE 2.5G
ADBPN-8143 QP-3 NOZZLE 3.75
ADBPN-8023 QP-3 NOZZLE 5
ADBPN-8203 QP-3 NOZZLE 5G
ADBPN-8213 QP-3 NOZZLE 8G
ADBPN-8223 QP-3 NOZZLE 15G
ADBPN-8233 QP-3 NOZZLE 17.5G
ADBPN-8180 QP-3 NOZZLE SINGLE 20 L=270
ADBPN-8440 QP-3 NOZZLE SINGLE 20 L=200
ADBPN-8340 QP-3 NOZZLE SINGLE 20 L=110
ADBPN-8341 QP-3 NOZZLE SINGLE 23G (for BGA)
FUJI QP242 QP132 INDEX SMT NOZZLE
Part Number Description
ABHPN – 8510 QP-S-12 -Ø 0.7
ABHPN – 8520 QP-S-12 NZ. Ø 1.0
ABHPN – 8530 QP-S-12 NZ. Ø 1.3 / 1.0
ABHDN – 8560 QP-M-38 NZ. Ø 2.5 / 1.9
ABHDN – 8570 QP-M-38 NZ. Ø 3.7 / 1.7
ABHPN – 8590 QP-L-47 NZ. Ø 7.0
CGPN-8036 QP132 Ø0.7 / Ø0.4
CGPN-80250 QP132 Ø1.0 / Ø0.7
CGPN-8015 QP132 Ø1.3 / Ø0.9
FUJI CP3 DARKPOINT SMT NOZZLE
Part Number Description
AGPH – 9560 FUJI CP3/S SMT NOZZLE Ø 0.7
AGPH – 9410 FUJI CP3/S SMT NOZZLE Ø 1.0
AGPH – 9130 FUJI CP3/S SMT NOZZLE Ø 1.3
AGPH – 9050 FUJI CP3/S SMT NOZZLE Ø 1.3 (MELF)
AGPH – 9470 FUJI CP3/L SMT NOZZLE Ø 1.3
AGPH – 9060 FUJI CP3/L SMT NOZZLE Ø 2.5
AGPH – 9430 CP3/L Ø 3.4
AGPH – 9460 CP3/L Ø 1.3 (MELF)
AGPH – 9570 CP3/DPT-S DARK POINT Ø 0.7/ Ø 11.5
AGPH – 9550 CP3/DPT-S DARK POINT Ø 1.0/ Ø 11.5
AGPH – 9190 CP3/DPT-S DARK POINT Ø 1.3/ Ø 11.5
AGPH – 9200 CP3/DPT-S DARK POINT Ø 2.5/ Ø 16.5
AGPH – 9440 CP3/DPT-S DARK POINT Ø 3.4/ Ø 16.5
FUJI CP4 CP6 CP7 SMT NOZZLE
Part Number Description
AMPH – 8710 CP4/S Ø 0.7
AMPH – 8720 CP4/S Ø 1.0
AMPH – 8730 CP4/S Ø 1.3
AMPH – 8740 CP4/S Ø 1.8
AMPH – 8750 CP4/S Ø 2.5
AMPH – 8760 CP4/L Ø 2.5
AMPH – 8770 CP4/L Ø 3.7
AMPH – 8780 CP4/L Ø 5.0
AWPH – 9510 CP6/S Ø 0.7
AWPH – 9520 CP6/S Ø 1.0
AWPH – 9530 CP6/S Ø 1.3
AWPH – 9550 CP6/S Ø 1.8
AWPH – 9541 CP6/S Ø 1.3 (MELF)
AWPH – 9580 CP6/L Ø 2.5
AWPH – 9600 CP6/L Ø 3.7
AWPH – 9591 CP6/L Ø 2.5 (MELF)
AWPH – 9560 CP6/M Ø 2.5
ADCPH – 9510 CP7/S Ø0.4 (8mm Diameter)
ADCPH – 9520 CP7/S Ø0.7 (8mm Diameter)
ADCPH – 9530 CP7/S Ø1.0 (8mm Diameter)
ADCPH – 9540 CP7/S Ø1.3 (8mm Diameter)
ADCPH – 9700 CP7/S Ø1.3 (8mm Diameter) MELF
ADCPH – 9550 CP7/S Ø1.8 (16mm Diameter)
ADCPH – 9560 CP7/L Ø2.5 (16mm Diameter)
ADCPH – 9710 CP7/L Ø2.5 (16mm Diameter) MELF
ADCPH – 9570 CP7/L Ø3.7 (16mm Diameter)
ADCPH – 9580 CP7/L Ø5.0 (16mm Diameter) SQUARE
FUJI IP IP2 IP3 SMT NOZZLE
Part Number Description
IPH – 3431 FUJI IP SMT NOZZLE – SS NOZZLE Ø 1.0
IPH – 3421 FUJI IP SMT NOZZLE – S NOZZLE Ø 1.3
IPH – 3411 FUJI IP SMT NOZZLE – M NOZZLE Ø 2.5
IPH – 3401 FUJI IP SMT NOZZLE – L NOZZLE Ø 4.0
IPH – 4511 FUJI IP SMT NOZZLE – LL NOZZLE Ø 7.0 (WITH CAP)
IPH – 4520 IP – LL NOZZLE Ø 10.0 (WITH CAP)
IPH – 4531 IP – LL NOZZLE Ø 15.0 (WITH CAP)
IPH – 4541 IP – LL NOZZLE Ø 20.0 (WITH CAP)
AKPH – 2051 IP2 – SS Ø 1.0 (FIXED)
AKPH – 2031 IP2 – S Ø 1.3 (FIXED)
AKPH – 2041 IP2 – M Ø 2.5 (FIXED)
AKPH – 2061 IP2 – L Ø 4.0 (FIXED)
AQNA – 3130/39 IP3 – Ø 1.3 (FIXED) (31 x 31mm)
AQNA – 3140/49 IP3 – Ø 1.8 (FIXED) (31 x 31mm)
AQNA – 3150/59 IP3 – Ø 2.5 (FIXED) (31 x 31mm)
AQNA – 3160/69 IP3 – Ø 3.7 (FIXED) (31 x 31mm)
AQNA – 3170 IP3 – Ø 7.0 (FIXED) (31 x 31mm)
AQNA – 3180 IP3 – Ø 10.0 (FIXED) (52 x 52mm)
AQNA – 3190 IP3 – Ø 15.0 (FIXED) (62 x 62mm)
AQNA – 3200/01 IP3 – Ø 20.0 (FIXED) (102 x 102mm)
AQNA – 3290/95 IP3 – Ø 3.7 (FIXED) (52 x 52mm)
AQNA – 3300/04 IP3 – Ø 7.0 (FIXED) (52 x 52mm)
AQNA – 3310/14 IP3 – Ø 10.0 (FIXED) (62 x 62mm)
AQNA – 3320/24 IP3 – Ø 15.0 (FIXED) (102 x 102mm)
AQNA – 3330/34 IP3 – Ø 6.5 (FIXED) (52 x 52mm)
IPA – 0007 IP – LL ADAPTOR Ø 7.0
IPA – 0010 IP – LL ADAPTOR Ø 10.0
IPA – 0015 IP – LL ADAPTOR Ø 15.0
IPA – 0020 IP – LL ADAPTOR Ø 20.0
FUJI QP QP132 QP242 QP341 SMT NOZZLE
Part Number Description
BHPN – 3271 QP SMT NOZZLE SPRING PLATE
BHPN – 3232 QP SMT NOZZLE SPRING PLATE
ABHPN – 6246 – Ø 2.5
ABHPN – 6256 – Ø 3.75
ABHPN – 6276 – Ø 7.0
ABHPN – 6365 – Ø 7.0
ABHPN – 6852 – Ø 5.0 (W/RUBBER CUP)
ABHPN – 6893 – Ø 8.0 (W/RUBBER CUP)
ABHPN – 6803 – Ø 15.0 (W/RUBBER CUP)
ABHPN – 6703 – Ø 17.5 (W/RUBBER CUP)
CGPN-8036 QP132 Ø0.7 / Ø0.4
CGPN-80250 QP132 Ø1.0 / Ø0.7
CGPN-8015 QP132 Ø1.3 / Ø0.9
ABHPN – 8510 QP-S-12 -Ø 0.7
ABHPN – 8520 QP-S-12 NZ. Ø 1.0
ABHPN – 8530 QP-S-12 NZ. Ø 1.3 / 1.0
ABHDN – 8560 QP-M-38 NZ. Ø 2.5 / 1.9
ABHDN – 8570 QP-M-38 NZ. Ø 3.7 / 1.7
ABHPN – 8590 QP-L-47 NZ. Ø 7.0
2AGKNX005100, NOZZLE FUJI NXT Head H24 Dia. 0.3
2AGKNX005200, NOZZLE FUJI NXT Head H24 Dia. 0.35
2AGKNX005300, NOZZLE FUJI NXT Head H24 Dia. 0.4
2AGKNX005500, NOZZLE FUJI NXT Head H24 Dia. 0.5
2AGKNX003100, NOZZLE FUJI NXT Head H24 Dia. 0.7
2AGKNX003200, NOZZLE FUJI NXT Head H24 Dia. 0.8
2AGKNX003500, NOZZLE FUJI NXT Head H24 Dia. 1.0
2AGKNX001700, NOZZLE FUJI NXT Head H24 Dia. 1.3
2AGKNX004000, NOZZLE FUJI NXT Head H24 Dia. 1.3MELF
2AGKNX003700, NOZZLE FUJI NXT Head H24 Dia. 1.8
2AGKNX004100, NOZZLE FUJI NXT Head H24 Dia. 1.8MELF
2AGKNX003900, NOZZLE FUJI NXT Head H24 Dia. 2.5
2AGKNX001400, NOZZLE FUJI NXT Head H24 Dia. 2.5G
2AGKNX004200, NOZZLE FUJI NXT Head H24 Dia. 2.5MELF
2AGKNX007500, NOZZLE FUJI NXT Head H24 S typ
2AGKNX007600, NOZZLE FUJI NXT Head H24 M type
2UDLFA001400
|
W04b |
UF08600 |
UF08700 |
||
|
W8 |
UF02300 |
UF07700 |
UF00500 |
UF01300 |
|
W8（0402） |
UF04100 |
UF07800 |
UF04200 |
UF04300 |
|
W08c |
UF09700 |
2UDLFA0002 |
UF09800 |
UF09900 |
|
W12 |
UF00600 |
UF00700 |
UF01400 |
|
|
W12c |
UF10000 |
UF10100 |
UF10200 |
|
|
16周 |
UF00800 |
UF01500 |
||
|
W16c |
UF10300 |
UF10400 |
||
|
W24 |
UF00900 |
UF01600 |
||
|
W24c |
UF10500 |
UF10600 |
||
|
W32 |
UF01000 |
UF01700 |
||
|
W32c |
UF10700 |
UF10800 |
||
|
W44 |
UF01100 |
UF01800 |
||
|
W44c |
UF10900 |
UF11000 |
||
|
W56 |
UF01200 |
UF01900 |
||
|
W56c |
UF11100 |
UF11200 |
||
|
W72 |
UF05200 |
UF02500 |
||
|
W88 |
UF05300 |
UF02600 |
||
|
W104 |
UF05000 |
UF09600 |
粤ICP备16109214号
